Special Features： |
| |
- Machine speed：250m/min
- Low tension design：30~200N/Web
- Coating weight：2.5~25gsm
- Dryer temperature up to 200°C
(water-base)
- Design for web surface treatment,
such as PP paper, Stamping foil
film, Lamination film, Label film,
Release film, and various films.
- Process design for customer caring.
- Modulized coater head design
can mach EG3 explosion-proof standard.
- Three types of oven for option
roller-driving oven, floating oven
and semi-floating oven.
|
 |
|
| > |
Human-Machine interface
system |
| |
Human machine interface system substituted
of buttons, switches, timers and meters. It
id easy to set comprehensive processing parameters
for the different factor of production and
to monitor machine running status.
Auto-alarm system also connects with human-machine
interface which show any abnormal stop or
interruption immediately on monitor. (Furnished
with operation and maintenance manuals) |
| > |
Heating & Cooling
Oven： |
| |
Three types of oven for option
 |
Floatation |
| |
- Web supported by air in the oven
to avoid scratching problem.
- Pin-hole problem solution.
- Double side heating can shorten
drying time to get energy saving.
|
|
Roller-Driving oven |
| |
- The film moving by driven roller.
- For all sorts of web drying.
- The best buy for coat reduction.
|
|
Semi-Floatation Oven |
| |
- Double side heating can shorten
drying time go get energy saving.
- For sorts of webs, like papers,
films, etc.
- It’s easy to operate and change
different products.
|
|
| > |
Unwinder / Winder： |
| |
- Max. unwinding / winding diameter：∮1050mm
- 3” or 6” paper core alternative.
- Automatic tension control.
- Near roll or touch roll winding
mode alternative.
- Full speed auto-splicing and reversible
running available.
- Option:
Hydraulic lifter unit.
|
 |
|
| > |
Coating Mechanism： |
| |
- Suitable for low viscosity or water-based
glue.
- Coating weight：2.5~25gsm
- High precision mechanism for superior
coating effect.
- Modulized coater head is modular design
to meet customers’ requirements.
- EG3 exposion-proof standard.
|
| > |
X-bar Optional： |
| |
| Web reversible mechanism
makes double-side coating easyer, and
twice coating on same side. |
 |
|
Web Surface Coating
